Invincible General Electric Ride-On Sweeper

Invincible General Electric Ride-On Sweeper

Invincible General

Consult

Features
Technical Indicators
Overall Dimension

Subversive innovation, no need to dump garbage ABM Invincible General sweeper adopts conveyor belt into the barrel and no need to dump garbage, which is subversive and innovative, eliminating the labor and secondary pollution of dumping garbage. It is suitable for cleaning large areas such as streets, communities, schools, properties, factories, sanitation, municipal administration, gardens, etc. Innovative advantages of Invincible General 1. Smart cleaning IoT system imported from Italy The smart cleaning IoT system imported from Italy, with full integrated circuit control board docking, can remotely control the machine operation status through computers and mobile phones, including machine walking trajectory, real-time work data monitoring, the working status of the whole machine and each component, and accurately transmit the fault to the mobile phone, so that managers can see it at a glance, service support is one step ahead, and reduce after-sales service costs. 2. Chip-type high-integration electronic control system Chip-type high-integration electronic control system, advanced technology level, automatic short-circuit protection, automatic stop of overcurrent protection, simple and fast machine maintenance. 3. Humanized car handbrake Sedan-style handbrake, comfortable and high-end feel, easy to operate, and high reliability. 4. National standard 240L trash bin Connected to the domestic general 240 trash bin, convenient for garbage transfer after cleaning; and equipped with trash bin full load sensor, the sensor senses that the trash bin is full, and automatically alarms to remind the staff (it can be installed with garbage full, and the cleaning function automatically stops). 5. Patented shock absorption The shock absorption system of this machine adopts a double-rod balanced connection structure, combined with high-quality hydraulic damping shock absorption springs, the shock absorption effect is stable and does not shake, greatly improving the comfort of operation and reducing failures caused by vehicle body vibration. 6. Can be equipped with high-pressure water gun (1) High-pressure water pump: high-pressure water spray, convenient for washing daily stains, garbage at the bottom of the vehicle, etc.; (2) Angle adjustment nozzle: manual adjustment nozzle system, flexible operation. 7. Can be equipped with LED advertising screen The LED advertising screen at the rear of the vehicle can be used to display advertisements. 8. Can be equipped with multimedia
Project Name
Unit
parameter
List of main technical advantages
Sweeping width
MM
2200
Patented shock absorption system
Patented design! Reduce machine failures caused by vibration and improve operating comfort.
Maximum cleaning efficiency
M²/H
25000
Italian imported smart cleaning IoT system
The smart cleaning IoT system imported from Italy is connected to a fully integrated circuit control panel.
The machine's operating status can be remotely controlled via a computer or mobile phone,including the machine's travel trajectory, real-time work data monitoring, and the working status of the entire machine and its components. Fault codes are transmitted to the mobile phone, allowing managers to see them clearly and provide service support one step ahead.
Battery life
H
6-8
Trash bin capacity
L
240
Filter area
(filter element)
M²
10x2
Chip-type highly integrated electronic control system
Chip-type highly integrated electronic control system, advanced technology level, automatic short-circuit protection, automatic shutdown in case of overcurrent, simple and quick machine maintenance.
Main brush size
MM
700
Front brush size
MM
600
High efficiency
The maximum working efficiency can reach 25,000m2/h, and one machine can replace 16-20 workers.
Back brush size
MM
550
   Powerful filtration
Equipped with 2 rare earth permanent magnet dust suction fans, the 20 square meter filtration area far exceeds the traditional one by 100%.
Maximum driving speed
KM/H
18
Cleaning speed
KM/H
7-12
   Super climbing ability
It adopts an ultra-large torque reduction drive axle with a designed 3 times overload capacity. It is stable and reliable, and its climbing ability is comparable to that of a car.
Gradeability
%
35
   Drive axle
Ultra-quiet stepless speed-changing rear axle, integrated floating load-bearing design, profiled and ground gear design, no noise, no oil leakage.
Power Source
V
60
Machine weight
KG
1500
Super national standard 240L trash can
Use national standard 240L environmentally friendly trash can, and the trash can space is 100% utilized.
Operating power
W
Main brush 700+ fan 600x2+
Transmission 300+ edge steel 100x4+
high pressure spray gun 500+
dust vibration 80
Super long battery life
Adopting the world's top technology lead-acid maintenance-free power battery, it has long-lasting power and requires no maintenance. Optional lithium battery is available.
Drive power
W
4.5T
4500(AC drive)
Easy to clean filter
Large imported material filter, built-in electric dust collector, daily filter cleaning,no need to remove the filter, simple and quick.
Total Power
W
7680(AC drive)
   Stable overall performance
Engineering-grade design, manufactured strictly in accordance with enterprise standards, stable performance and low maintenance cost.
Mist spray water tank
L
100
Easy maintenance
The structural design is neat and elegant, and all internal parts are clearly visible, making it convenient for personnel to carry out daily maintenance.
Air conditioner

Optional
Lithium battery rate

Optional
Intimate intelligent tips
Humanized design, automatic alarm prompts when the trash can is about to be full, making it more worry-free to use.
Tail LED advertising screen

Optional
Can be equipped with high pressure water gun
High-pressure water spray is convenient for washing daily stains, garbage under the vehicle, etc.
High pressure water gun

Optional
Car handbrake, safe and reliable
Super strong braking performance,can stop within 2 meters at full speed, and is equipped with an emergency power-off switch.
Size (length*width*height)
MM
3120*2200*1950

Project Name	Unit	parameter	List of main technical advantages
Sweeping width	MM	2200	Patented shock absorption system	Patented design! Reduce machine failures caused by vibration and improve operating comfort.
Maximum cleaning efficiency	M²/H	25000	Italian imported smart cleaning IoT system	The smart cleaning IoT system imported from Italy is connected to a fully integrated circuit control panel. The machine's operating status can be remotely controlled via a computer or mobile phone,including the machine's travel trajectory, real-time work data monitoring, and the working status of the entire machine and its components. Fault codes are transmitted to the mobile phone, allowing managers to see them clearly and provide service support one step ahead.
Battery life	H	6-8
Trash bin capacity	L	240
Filter area (filter element)	M²	10x2	Chip-type highly integrated electronic control system	Chip-type highly integrated electronic control system, advanced technology level, automatic short-circuit protection, automatic shutdown in case of overcurrent, simple and quick machine maintenance.
Main brush size	MM	700	Chip-type highly integrated electronic control system
Front brush size	MM	600	High efficiency	The maximum working efficiency can reach 25,000m2/h, and one machine can replace 16-20 workers.
Back brush size	MM	550	Powerful filtration	Equipped with 2 rare earth permanent magnet dust suction fans, the 20 square meter filtration area far exceeds the traditional one by 100%.
Maximum driving speed	KM/H	18	Powerful filtration
Cleaning speed	KM/H	7-12	Super climbing ability	It adopts an ultra-large torque reduction drive axle with a designed 3 times overload capacity. It is stable and reliable, and its climbing ability is comparable to that of a car.
Gradeability	%	35	Drive axle	Ultra-quiet stepless speed-changing rear axle, integrated floating load-bearing design, profiled and ground gear design, no noise, no oil leakage.
Power Source	V	60	Drive axle
Machine weight	KG	1500	Super national standard 240L trash can	Use national standard 240L environmentally friendly trash can, and the trash can space is 100% utilized.
Operating power	W	Main brush 700+ fan 600x2+ Transmission 300+ edge steel 100x4+ high pressure spray gun 500+ dust vibration 80	Super long battery life	Adopting the world's top technology lead-acid maintenance-free power battery, it has long-lasting power and requires no maintenance. Optional lithium battery is available.
Drive power	W	4.5T 4500(AC drive)	Easy to clean filter	Large imported material filter, built-in electric dust collector, daily filter cleaning,no need to remove the filter, simple and quick.
Total Power	W	7680(AC drive)	Stable overall performance	Engineering-grade design, manufactured strictly in accordance with enterprise standards, stable performance and low maintenance cost.
Mist spray water tank	L	100	Easy maintenance	The structural design is neat and elegant, and all internal parts are clearly visible, making it convenient for personnel to carry out daily maintenance.
Air conditioner		Optional	Easy maintenance
Lithium battery rate		Optional	Intimate intelligent tips	Humanized design, automatic alarm prompts when the trash can is about to be full, making it more worry-free to use.
Tail LED advertising screen		Optional	Can be equipped with high pressure water gun	High-pressure water spray is convenient for washing daily stains, garbage under the vehicle, etc.
High pressure water gun		Optional	Car handbrake, safe and reliable	Super strong braking performance,can stop within 2 meters at full speed, and is equipped with an emergency power-off switch.
Size (lengthwidthheight)	MM	312022001950	Car handbrake, safe and reliable
