Project Name | Unit | Parameter | List of main technical advantages | |
Cleaning width | mm | 1800 | Super climbing ability | It adopts an ultra-large torque reduction drive axle with a designed 3 times overload capacity. It is stable and reliable, and its climbing ability is comparable to that of a car. |
Work efficiency | m²/h | 13000 | ||
Climbing ability | % | 35 | ||
Main brush length | mm | 700 | Drive axle | Ultra-quiet stepless speed-changing rear axle, integrated suspension load-bearing design, profiled and ground gear design, no noise, no oil leakage. |
Side brush diameter | mm | 500 | ||
Filter area | m2 | 6 | ||
Power source | V | 48V100A (standard) 48V120A (optional) | Super long battery life | Adopting the world's top technology maintenance-free power battery, it has long-lasting power and requires no maintenance. |
Working time | h | 4-6 | ||
Water tank capacity | L | 60 | ||
Trash tank capacity | L | 170 | Easy to clean filter | Large imported material filter, built-in electric dust collector, daily filter cleaning, no need to remove the filter, simple and quick. |
Drive power | W | 2500 | ||
Operation power | W | Main brush 700 + fan 420 + side brush 100*4 + dust shaker 80 | ||
Travel speed | km/h | 10 | Stable overall performance | Engineering-grade design, manufactured strictly in accordance with enterprise standards, stable performance and low maintenance cost |
Operating speed | km/h | 6-8 | ||
Total power | W | 4100 | Easy maintenance | The structural design is neat and elegant, and all internal parts are clearly visible, making it convenient for personnel to carry out daily maintenance. |
Net weight | kg | 680 | ||
Dimensions | mm | Length 2250*Width 1800*Height 2000 | ||
